CCM Vision Alignment Cutting Machine
Machine-vision aligned cutting for CCM at micron-level accuracy.
A vision-guided cutting system for catalyst-coated membranes (CCM). An industrial camera aligns each cut to the printed pattern, holding tight positioning and flatness tolerances across the cutting platform.
Key Specifications
| Platform flatness accuracy | ±0.008 mm |
| Parallelism accuracy | ±0.01 mm |
| Displacement accuracy | ±0.008 mm |
| Pressure sensor accuracy | ±0.05% FS |
| Servo motor power | 2.2–4 kW (by model) |
| Vision system power | ~0.5 kW |
| Typical cycle | 30–60 s |
| Cutting range / Camera spec | Customized — per project |
Core precision parameters are fixed; dimensions, tonnage, tooling and process recipe are customized to your application.
Applications
CCM trimming and shaping in PEM fuel cell and electrolyzer MEA lines.
